TEX:
Submersible electric pumps for waste water, passage of solid bodies up to 28 mm.
TEX-D:
Submersible electric pumps for drainage, passage of solid bodies up to 4mm.
Materials
Cast iron, brass.
| Maximum Flow Rate | 39 | m³/h | |
| Maximum Head | 18 | m | |
| Maximum Power | 1,5 | kW |
Submersible electric pumps for drainage and waste water, suitable for the difficult, complex and often extreme working conditions required in this sector. These pumps stand out for their quality, solidity, compact size, design, reliability, ease of use and low running costs.
Materials
Cast iron, stainless steel.
| Maximum Flow Rate | 516 | m³/h | |
| Maximum Head | 40 | m | |
| Maximum Power | 22 | kW |
• Anti clogging vortex impellers
• Multi-channel helical open impeller to pump charged liquids
• Multi-channel open impeller with helical channel wear disc. Minimized risk of clogging
• Closed peripheral impeller for top efficiency in pumping charged liquids with low fibrous substances
Cost saving product with low energy consumption.
Exclusive protection for the double mechanical seal.
Materials
Cast iron, stainless steel AISI 316, DUPLEX 5A
| Maximum Flow Rate | 400 | m³/h | |
| Maximum Head | 30 | m | |
| Maximum Power | 22 | kW |
Suitable for pumping domestic and industrial foul water, viscous and corrosive liquids, liquids with fibrous and solid substances, agricultural slurry, as well as generally dirty and muddy water.
Materials
Cast iron, stainless steel
| Maximum Flow Rate | 1600 | m³/h | |
| Maximum Head | 60 | m | |
| Maximum Power | 160 | kW |
Electric pump with open impeller allowing the passage of solid bodies up to 8 mm. Suitable for irrigation, agriculture and drainage.
Materials
Cast iron
| Maximum Flow Rate | 40 | m³/h | |
| Maximum Head | 18,7 | m | |
| Maximum Power | 2,2 | kW |
Motor pumps used in the agricultural and surface irrigation sector and in construction for drainage of excavations, channels and basins. Passage of solid bodies up to maximum size of 8 mm.
Materials
Cast iron
| Maximum Flow Rate | 45 | m³/h | |
| Maximum Head | 25,5 | m | |
| Maximum Power | 4,5 | kW |
Stainless steel drainage pumps with jacket cooling
Spherical clearance
10 mm
Discharge size
G1 1/4
Max. head
8,0 m
Max. flow
10,0 m³/h
Motor power P1
0,53 kW
Motor power P2
0,34 kW
Stainless steel drainage pumps with jacket cooling and Vortex impeller
Spherical clearance
20 / 30 mm
Discharge size
G1 1/4 / G2
Max. head
7,3 – 12,0 m
Max. flow
11,5 – 25,0 m³/h
Motor power P1
0,63 – 2,2 kW
Motor power P2
0,45 – 1,1 kW
Universal drainage pumps
Spherical clearance
10 mm
Discharge size
G1 1/2
Max. head
8,0 – 11,0 m
Max. flow
19,0 – 24,0 m³/h
Motor power P1
0,65 – 1,1 kW
Motor power P2
0,5 – 0,75 kW
Wear resistant submersible pumps
Spherical clearance
10 mm
Discharge size
G1 1/2
Max. head
11,5 m
Max. flow
22,5 m³/h
Motor power P1
1,1 kW
Motor power P2
0,75 kW
Wear resistant submersible pumps
Spherical clearance
10 mm
Discharge size
G2 / G2 1/2
Max. head
16,7 – 20,5 m
Max. flow
41,0 – 55,2 m³/h
Motor power P1
1,6 – 2,6 kW
Motor power P2
1,2 – 2,2 kW
Cast iron submersible pumps for hot water
Spherical clearance
10 – 28 mm
Discharge size
G1 1/2
Max. head
10,0 – 12,5 m
Max. flow
19,5 – 25,5 m³/h
Motor power P1
0,7 – 1,2 kW
Motor power P2
0,5 – 0,9 kW
Fire brigade submersible pump, application approved to DIN 14425
Spherical clearance
8 mm
Discharge size
B fixed coupling
Max. head
16,0 m
Max. flow
50,4 m³/h
Motor power P1
1,8 kW
Motor power P2
1,4 kW
Cast iron submersible pumps with single channel or vortex impeller
Spherical clearance
28 mm
Discharge size
R1 1/2
Max. head
10,0 – 13,6 m
Max. flow
22,0 – 25,2 m³/h
Motor power P1
1,0 – 1,1 kW
Motor power P2
0,7 – 0,9 kW
Cast iron submersible pumps with single channel or vortex impeller
Spherical clearance
30 – 42 mm
Discharge size
G2
Max. head
6,4 – 19,0 m
Max. flow
31,0 – 42,1 m³/h
Motor power P1
1,0 – 1,6 kW
Motor power P2
0,7 – 1,2 kW
Cast iron submersible pumps with single channel or vortex impeller
Spherical clearance
50 mm
Discharge size
G2
Max. head
11,5 – 14,5 m
Max. flow
26,0 – 35,0 m³/h
Motor power P1
1,5 kW
Motor power P2
1,1 kW
Stainless steel submersible pumps with single channel or vortex impeller
Spherical clearance
35 – 50 mm
Discharge size
G1 1/2 / 2
Max. head
9,0 – 12,7 m
Max. flow
16,5 – 28,0 m³/h
Motor power P1
1,1 – 2,2 kW
Motor power P2
0,76 – 1,2 kW
Drainage pumps for higher heads
Discharge size
G2 – DN 50
Max. head
42,0 – 69,0 m
Max. flow
31 m³/h
Motor power P1
7,5 – 11,0 kW
Motor power P2
6,4 – 9,5 kW
Cast iron submersible pumps with single channel or vortex impeller
Spherical clearance
50 – 65 mm
Discharge size
G2 1/2
Max. head
7,5 – 31,6 m
Max. flow
28,8 – 72,9 m³/h
Motor power P1
1,0 – 5,2 kW
Motor power P2
1,0 – 4,4 kW
Cast iron submersible pumps with single channel or vortex impeller
Spherical clearance
50 – 65 mm
Discharge size
G3
Max. head
7,5 – 30,0 m
Max. flow
28,8 – 82,0 m³/h
Motor power P1
1,0 – 5,2 kW
Motor power P2
0,8 – 4,4 kW
Stainless steel submersible pumps with single channel impeller
Spherical clearance
50 mm
Discharge size
G2 1/2
Max. head
10,5 – 31,4 m
Max. flow
31,0 – 62,6 m³/h
Motor power P1
1,3 – 5,2 kW
Motor power P2
1,0 – 4,4 kW
Stainless steel submersible pumps with single channel impeller
Spherical clearance
70 mm
Discharge size
DN 80
Max. head
12,9 – 14,0 m
Max. flow
87,7 – 112,5 m³/h
Motor power P1
2,5 – 3,2 kW
Motor power P2
2,0 – 2,5 kW
Spherical clearance
70 mm
Discharge size
G3 / DN 80
Max. head
8,3 – 23,7 m
Max. flow
32,0 – 112,0 m³/h
Motor power P1
1,2 – 5,2 kW
Motor power P2
1,1 – 4,4 kW
Spherical clearance
80 – 100 mm
Discharge size
DN 80 / DN 100 / DN150
Max. head
4,8 – 42,2 m
Max. flow
72,0 – 390,0 m³/h
Motor power P1
1,7 – 43,0 kW
Motor power P2
0,0 – 25,4 kW
Speed
2900 / 1450 / 960 rpm
Spherical clearance
80 – 100 mm
Discharge size
DN 80 / DN 100 / DN150
Max. head
4,8 – 42,2 m
Max. flow
72,0 – 390,0 m³/h
Motor power P1
1,7 – 43,0 kW
Motor power P2
0,0 – 25,4 kW
Speed
2900 / 1450 / 960 rpm
Submersible sewage pumps with multi channel impeller
Discharge size
DN100 – DN400
Max. head
16,5 – 32,0 m
Max. flow
375,0 – 500,0 m³/h
Motor power P1
25,0 – 194,7 kW
Motor power P2
13,3 – 19,3 kW
Speed
2900 / 1450 / 960 rpm
Submersible sewage pumps with multi channel impeller
Spherical clearance
80 mm
Discharge size
2 – DN150
Max. head
2,1 – 31,8 m
Max. flow
343 – 400 m³/h
Motor power P1
17,0 – 22,0 kW
Motor power P2
14,6 – 19,3 kW
Speed
2800 / 1450 rpm
Submersible sewage pumps with single channel impeller
Spherical clearance
80 – 100 mm
Discharge size
DN 80 / DN 100 / DN150
Max. head
2,0 – 42,1 m
Max. flow
68,2 – 384,1 m³/h
Motor power P1
1,7 – 22,0 kW
Motor power P2
1,3 – 19,3 kW
Speed
2800 / 1450 rpm
Submersible sweage pumps with vortex impeller
Spherical clearance
80 – 100 mm
Discharge size
DN 80 / DN 100 / DN150
Max. head
1,0 – 58,8 m
Max. flow
43,8 – 133,0 m³/h
Motor power P1
1,7 – 28,0 kW
Motor power P2
1,3 – 25,4 kW
Speed
2900 / 1450 rpm
Injektor-jet pipe system with submersible pumps for stormwater tanks
Discharge size
DN 100 / DN 150
Max. head
7,0 – 35,0 m
Max. flow
108,0 – 381,6 m³/h
Motor power P1
7,7 – 22,0 kW
Motor power P2
5,0 – 19,3 kW
Speed
1450 rpm
Submersible propeller pumps
Discharge size
DN 600 / DN 700 / DN 900 / DN 1000
Max. head
1,0 – 6,7 m
Max. flow
1160 – 8290 m³/h
Motor power P1
21,0 – 170,2 kW
Motor power P2
18,5 – 160,0 kW
Speed
730 / 1450 rpm
Submersible pumps with cutter system for sewage and effluent
Discharge size
G2
Max. head
24,0 – 26,0 m
Max. flow
10,5 – 11,0 m³/h
Motor power P1
1,5 kW
Motor power P2
1,2 kW
Cast iron submersible pumps with cutter system for pressure sewage systems
Discharge size
G2 / DN50
Max. head
20,4 – 52,0 m
Max. flow
11,7 – 27,7 m³/h
Motor power P1
1,3 – 5,2 kW
Motor power P2
0,9 – 4,4 kW
Cast iron submersible pumps with cutter system for pressure sewage systems
Discharge size
DN 50
Max. head
42,0 – 68,0 m
Max. flow
30,7 m³/h
Motor power P1
7,5 – 11,0 kW
Motor power P2
6,4 – 9,5 kW
ASC-System for MX,K pumps
Spherical clearance
80 – 100 mm
Discharge size
DN 80 – DN 150
Speed
2900 / 1450 / 960 rpm
Submersible sewage pumps with self cleaning semi-open OC impeller with cutting edges
Discharge size
DN 100
Max. head
32,9 – 51,5 m
Max. flow
122,0 – 130,3 m³/h
Motor power P1
7,3 – 16,0 kW
Motor power P2
6,4 – 14,4 kW
Speed
2.900 rpm
